Club 3D 100W 12-1 USB-C Triple Display PD3.0 Docking Station and Charger CSV-2541

Club 3D 100W 12-1 USB-C Triple Display PD3.0 Docking Station and Charger CSV-2541

The CSV-2541 is a USB Type-C 10Gbps 12-in-1 Triple Displays Docking Station with 2x HDMI, 1x DisplayPort, 1x USB Type-C data port, 3x USB Type-A, RJ45, Card reader ,3.5mm audio port and USB Type-C charging port, providing an ideal solution for extending the USB Type-C or Thunderbolt host, especially for those host with a single USB Type-C port. With bottom bracket design, it can be a stable stand for your laptops.

•  ERGONOMIC Design : Place your laptop on the docking station, plug in USB-C and enjoy better connectivity, thermal and cable management for your setup.
• GBASE-T GIGABIT ETHERNET: Features a 1Gbps network controller that delivers speeds of 10/100/1000 Mbps; For laptops / devices without an Ethernet.
• 12 PORTS from one USB Type-C: Expand the connectivity of a USB Type-C computer by adding Four USB Ports (3x USB Type-A, 1x Type-C) a Power Delivery 3.0 USB Type-C Port Max. 100Watt upstream.
• 2 dedicated Card reader slots MicroSD/SD supports SD3.0(UHS-I) with max 104Mbps, card slots work simultaneously.

Specifications

Video Input: USB-C
Video Output: 2 × HDMI, DisplayPort
Host Port: USB-C DP 1.4 Alternate Mode
Connectors: 2 × HDMI, DisplayPort 1.4, 1G Ethernet, Audio/Mic, MicroSD / SD 3.0, USB-C PD, 3 × USB-A 5Gbps
Colour: Black
Features: MST, Kensington anti-theft lock
OS Support: Windows 11
Wattage: 100W
Chipset: RTD2146, VL103-Q4, ALC4032, VL822 / 8176S, RTL8153B, GL3224, GPY2110VC
Maximum Resolution: 8K@30Hz
Supported Resolutions: 8K@30Hz, 4K@120Hz (DSC)
Dual-Screen Support: 4K@60Hz (DSC)
Triple-Screen Support: 4K@60Hz + 2 × 4K@30Hz (DSC)

What's in the box

• USB-C Docking Station
• Power Adapter
• User Manual
