Dahua EVS5036S-R 36 HDD Enterprise Video Storage

Dahua EVS5036S-R 36 HDD Enterprise Video Storage

Specifications:

Main Processor: 64-bit high-performance Intel processor

Controller: Single controller

Memory: 4GB by default

Operating System: Embedded LINUX

User Interface: Web

Video Stream Mode: 320-channel (640Mbps) incoming and recording , 160-channel (320Mbps)forwarding, 32-channel (64Mbps) playback

IP SAN Mode

• Storage bandwidth ≤2.7Gbps
• Write-through: 320Mbps;Write-back: 480Mbps

HDD Amount

• 36 HDDs, Up to 10 TB capacity for each HDD
• SATA HDD composite connection

miniSAS: 1 miniSAS ports, for storage extension

HDD Installation: Additional HDD bracket, HDD hot-swap, HDD online replacement

HDD Mode: Single, RAID 0/1/5/6/10/50/60(Enterprise-level HDDs are recommended), JBOD, hotspare

HDD Manager: Non-working HDD hibernation to guarantee sound ventilation, reduce power consumption and enhance HDD life span HDD bad track mapping to enhance HDD life span

RAID Rebuild: Dynamically adjust RAID rebuild speed to guarantee system load balance

Logic Volume Manager: Support iSCSI volume management, NAS(SMB/NFS/FTP) volume management

Snapshot: Support snapshot function, create user volume to back data.

Extract Frame: Support extracting P frame function. Customizied extracting period and frame rate setup.

Cluster Service: N+M cluster service

ANR: After diconnection, system can download the record file from the SD card on the network camera to maintain the full record file.

Shortcut RAID Creation: Click one button to create RAID conveniectly.

Search Mode: Time/Date, Channel, Alarm, MD and Exact Search (accurate to second)

Playback Function: Play, Pause, Stop, Fast play, Slow play, Full screen, Backup selection, Digital zoom

Backup Mode: USB Device/Network/eSATA Device

Third-party Support: Dahua, AEBell, Arecont, AXIS, Dynacolor, HIKVISION, LG, Panasonic, PSIA, Samsung, Sony, Vivotec, and more

Recording

IP Camera Input: 320 Channel

Record Rate: 640 Mbps

Record Mode: Manual, Schedule(Regular, Continous), Motion Detection, Alarm

Record Interval

• 1 ~ 120 min(default 60 min)
• Pre-record 1 ~ 30 sec, Post-record 10 ~ 300 sec.
• I frame storage by period.

USB: 2 USB 3.0

eSATA: 1 eSATA

RS232: 1 Port, for PC communication and Keyboard

Interface

• 1 management RJ-45 ports (10/100/1000Mbps)
• 4 data RJ-45 ports (10/100/1000Mbps)

Network Mode: Multi-address, Fault-tolerance, Load balance, Link aggregation

Network Function: HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTP, RTCP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, iSCSI, SMB, NFS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.)

Expansion Interface: 2 Ten Gigabit Optical Fiber Interface

Max. User Access: 128 users

Smart Phone: iPhone, iPad, Android

Interoperability: ONVIF 2.4, CGI Conformant
