Epson Agile EB-770F 4100 ANSI Lumens Ultra-short Throw Laser Projector V11HA79080

Epson Agile EB-770F 4100 ANSI Lumens Ultra-short Throw Laser Projector V11HA79080

Whatever the size of class or meeting room, unrestricted and immersive presentations are possible with this bright, clear, compact and affordable display solution.The EB-770F's bright, 1080p image, scalable up to 150", is clearly visible from every angle and at a distance, and content can easiliy be shared or streamed directly from multiple devices for the ultimate collaborative experience.

• Scalable FHD display for any room - 49-150" UST display for unrestricted viewing (no shadows/reflections)
• Bright and energy efficient laser - 4,100lm CLO with 3LCD technology for brighter colours at only 205W
• Effortless connectivity options - Auto-on, wired / wireless display with USB 2A output for smart sticks
• Simple to use and built to last - Virtually maintenance free with 5-year, 12,000hr warranty
• Document camera compatibility - Create and record a live, totally immersive lesson or presentation

The EB-770F's ultra short throw lens allows safe, discreet positioning close to the display, enabling presenters free access to perform without casting shadows.

With 4,100 lumens CLO and 3LCD technology, the display is bright and vibrant up to 150", clearly visible from all angles and at a distance.

The experience is immersive and user-friendly.Scalable from 49-150", display sizes can be optimised for each room with one product and a fixed cost, and the EB-770F supports multi-projection edge-blending for a low cost, large, seamless, energy efficient 3780x1080p image.

Versatile wired and wireless connectivity options, including MiracastTM screen mirroring, ensures effortless, multi-device content sharing, and with a connected optional Epson visualiser, documents, presentations or 3D objects can be projected in incredible detail to the whole room.

Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots at certain angles, and teachers are not subjected to LCD panel direct blue light radiation, believed to damage eyes. Paired
with a hygienic, antibacterial whiteboard, teachers can annotate presentations with dry-wipe pens, or to save energy, simply use the whiteboard with the display turned off.

Specifications:

Projection System: 3LCD Technology, RGB liquid crystal shutter

LCD Panel: 0,62 inch with C2 Fine

Color Light Output: 4.100 Lumen- 2.800 Lumen (economy) In accordance with IDMS15.4

White Light Output: 4.100 Lumen - 2.800 Lumen (economy) In accordance with ISO 21118:2020

Resolution: 1080p

Resolution Enhancement: Full HD

Aspect Ratio: 16:9

Contrast Ratio: Over 5.000.000 : 1

Light source: Laser

Laser Light source: 20.000 hours Durability High, 30.000 hours Durability Eco

Keystone Correction: Manual vertical: ±3 °, Manual horizontal ±3 °

Colour Video Processing: 10 Bits

2D Vertical Refresh Rate: 192 Hz - 240 Hz

Colour Reproduction: Upto 1.07 billion colours

Throw Ratio: 0,25 - 0,35:1

Zoom: Digital, Factor:1 - 1,35

Lens: Optical

Screen Size: 60 inches - 150 inches

Projection Lens F Number: 1,6

Projection Lens Focal Length: 3,7 mm

Projection Lens Focus: Manual

Offset: 5 : 1

Interfaces: USB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only), Wi-Fi Direct, Microphone input

Epson iProjection App: Ad-Hoc / Infrastructure

Network Protocol: HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink

Security: Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection

Other features: 21:9 aspect ratio support, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, Network projection, OSD copy function, PC Free, Point correction, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App

Video Color Modes: Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM SIM, Multi Projection

Projector control: via: Crestron Integrated Partner, Crestron RoomView, Extron IP Link, AMX Device Discovery, Control4 Simple Device Discovery Protocol

Power consumption: 197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0,5 Watt (Energy saving standby)

Heat Dissipation: 895 BTU/hour (max)

Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz

Product dimensions: 356‎ x 395 x 133 mm (Width x Depth x Height)

Product weight: 5,9 kg

Noise Level: Normal:37 dB (A) - Economy:27 dB (A)

Supported Temperature: Storage -10° C - 60° C

Included Software: Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management

Loudspeaker: 16 Watt

In the Box:

• Power cable
• Projector feet
• Quick Start Guide
• Remote control incl. batteries
• Warranty document
