Fanvil Linkvil CS40 Conference Speakerphone

Fanvil Linkvil CS40 Conference Speakerphone

A loud speakerphone with vocal enhanced features designed for medium-sized meeting rooms

• Trio-mic with speaker - 5W Speaker for medium meeting rooms. Trio-omnidirectional microphone for 3m voice pickup range, ENC, ANS and AGC enabled.
• Flexible connectivity - USB Type-A/C and Bluetooth supported.
• Compatible with mainstream softphone platforms.
• Instant access touch buttons - Support for Pickup/Hangup, Play/Pause, Volume Up/Down, Mute, Bluetooth Softphone / UC commands supported.
• 8× Paired devices, 2× devices connected simultaneously.
• Elegant with a fabric covered speaker.
• Modern look with ambient light.

Specifications

Speaker

Speaker Size: φ52mm

Rated Power: 4Ω 5W

Max. Output Power: 8W

Root Mean Square (RMS): 5W

Sensitivity: 87dB ±2dB

Frequency Range: 100Hz~20KHz

Music-Mode Bandwidth: 100Hz~20KHz

Speak-Mode Bandwidth: 100Hz~8KHz

MICROPHONE

Type: 3× Omnidirectional Analogue Microphones

Voice Pickup Range: 3m

Sensitivity: -32dB Fs

Frequency Range: 20Hz~8KHz

Single noise ratio (SNR): >65dB

CONNECTIVITY

Connect to PC/Mobile Device: via USB Type-A/C and Bluetooth

Bluetooth: Ver. 5.4

Profiles: HSP V1.2, HFP V1.7, A2DP V1.2

Operating Range: 10m

Pairing List: up to 8× Devices

Simultaneous Connections: 2×

In the Box:

• CS40 Conferencing Speakerphone
• USB Cable
• Quick Start Guide
• Safety Information and Declaration
