Hikvision 8MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera DS-2CD2T87G2H-LISU/SL(4mm)

Hikvision 8MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera DS-2CD2T87G2H-LISU/SL(4mm)

Features:

• High quality imaging with 8 MP resolution
• Smart Hybrid Light: advanced technology with long range
• Clear imaging against strong back light due to 130 dB WDR technology
• Efficient H.265+ compression technology
• Focus on human and vehicle classification based on deep learning
• Active strobe light and audio alarm to warn intruders off
• Support on-board storage up to 512 GB (SD card slot)
• Provide real-time security via built-in two-way audio
• Audio and alarm interface available
• Water and dust resistant (IP67)

Technical Specifications:

Camera
Image Sensor: 1/1.8" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360°

Lens
Lens Type: Fixed focal lens, 2.8 mm and 4 mm optional
Focal Length & FOV:

• 2.8 mm: H 105.1°, V 54.8°, D 128.2°
• 4 mm: H 90.0°, V 45.8°, D 109.4°
  • Lens Mount: M16
  • Iris Type: Fixed
  • Aperture: F1.0
  • Depth of Field: 2.8 mm: 3.3 m–∞, 4 mm: 3.8 m–∞
  • DORI:
• 2.8 mm: D 89 m, O 35 m, R 17 m, I 8 m
• 4 mm: D 109 m, O 43 m, R 21 m, I 10 m

Illuminator
Supplement Light Type: IR, White Light
Supplement Light Range: Up to 60 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm

Video
Main Stream:

• 50 Hz: 25 fps (3840×2160, 3200×1800, 2688×1520, 1920×1080, 1280×720)
• 60 Hz: 24–30 fps depending on resolution

Sub-Stream:

• 50 Hz: 25 fps (1280×720, 640×480, 640×360)
• 60 Hz: 30 fps (1280×720, 640×480, 640×360)

Third Stream:

• 50/60 Hz: 10 fps (various resolutions, supported under certain settings)
  Video Compression: H.265/H.264/H.264+/H.265+ (main), H.265/H.264/MJPEG (sub), H.265/H.264 (third)
  Video Bit Rate: 32 Kbps–16 Mbps
  H.264 Type: Baseline, Main, High Profile
  H.265 Type: Main Profile
  Bit Rate Control: CBR, VBR
  Scalable Video Coding (SVC): Supported
  Region of Interest (ROI): 1 fixed region for main & sub-stream

Audio
Audio Type: Mono sound
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate: 16–320 Kbps depending on codec
Audio Sampling Rate: 8–48 kHz
Environment Noise Filtering: Yes

Network
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live View: Up to 6 channels
API: ONVIF Profile S/G/T, ISAPI, SDK, ISUP
User/Host: Up to 32 users (administrator, operator, user)
Security: Password protection, HTTPS, 802.1X, watermark, IP filter, WSSE/digest authentication, RTP/RTSP over HTTPS, TLS 1.1/1.2/1.3, host authentication (MAC)
Network Storage: NAS (NFS, SMB/CIFS), ANR
Client: iVMS-4200, Hik-Connect, Hik-Central
Web Browser: IE 10/11 (plugin), Chrome 57+, Firefox 52+, Edge 89+, plugin-free support

Image Parameters Switch: Yes
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR, Defog
SNR: ≥ 52 dB
Wide Dynamic Range (WDR): 130 dB
Privacy Mask: 4 programmable polygon masks

Interface
Ethernet: 1 RJ45 10/100 M adaptive
On-Board Storage: microSD/microSDHC/microSDXC up to 512 GB
Built-in Microphone: Yes, 1
Built-in Speaker: Max 2 W, 10 cm SPL 97 dB
Audio Input/Output: 1 input, 1 output, 2-core terminal block, 3.3 Vpp max
Alarm: 1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Reset Key: Yes

Event & Smart Event
Basic Event: Motion detection (with human/vehicle detection), video tampering, exceptions
Linkage: FTP/NAS/memory card upload, surveillance notification, capture, email, alarm output, recording, audible warning, strobe light
Smart Event: Scene change detection

Deep Learning Function
Face Capture: Yes
Perimeter Protection: Line crossing, intrusion, region entrance/exit with human/vehicle alarm support

General
Power: 12 VDC ±25%, 0.88 A, max 10.5 W, Ø5.5 mm coaxial plug, reverse polarity protection; PoE IEEE 802.3af Class 3, max 12.5 W
Material: Metal (front cover, body, bracket)
Dimensions: 286.7 × 93.3 × 91.2 mm (11.3 × 3.7 × 3.6 in)
Package Dimension: 386 × 156 × 155 mm (15.2 × 6.1 × 6.1 in)
Weight: 1205 g (2.7 lb), with package: 1920 g (4.2 lb)
Storage & Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity ≤95%

General Function: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
Language Support: 33 languages

Approval
EMC: CE-EMC, RCM, IC, KC
Safety: UL 62368-1, CB IEC 62368-1, CE-LVD EN 62368-1
Environment: CE-RoHS 2011/65/EU
Protection: IP67
