LinkQnet 3000W 24V Pure Sinewave Inverter

LinkQnet 3000W 24V Pure Sinewave Inverter

Simple Solution for Home and Office

• True double conversion on-line
• Built-in voltage cut-off protection and surge immunity
• Next-gen bridgeless PFC technology, line efficiency up to 96%
• Output power factor 1.0
• DC start function (cold start)
• Input L-N detection function
• Laser printer and ultrasound loads acceptable

Specifications:

Capacity: 3000VA / 3000W

Nominal Voltage: 208 / 220 / 230 / 240VAC

Voltage Range: 110~300VAC

Frequency: 40~70Hz

Power Factor: >0.99

THDi: <4% (Linear Load), <5% (Non-Linear Load)

Output Voltage: 208 / 220 / 230 / 240VAC

Voltage Regulation: ±1%

Frequency Range: 50/60Hz ±0.1%

Crest Ratio: 3:1 (Max.)

THDu: <3% (Linear Load), <5% (Non-Linear Load)

Transfer Time: Line Mode to Battery Mode, 0ms; Inverter to Bypass, 4ms (Typical)

Power Factor: 1

Waveform: Pure Sinewave
