OWC 5-port Thunderbolt 5 Hub OWCTB5HUB5P

OWC 5-port Thunderbolt 5 Hub OWCTB5HUB5P

Possibilities and Performance Perfection

Explore a new world filled with workflow possibilities and state-of-the-art performance with the OWC Thunderbolt 5 Hub. It’s the perfect compact connectivity solution to solve the big problem of not having enough Thunderbolt 5 ports. Now you can turn a single cable connection from your machine into three Thunderbolt 5 ports and one USB-A port. With up to 80Gb/s of bi-directional data speed – up to 2x faster than Thunderbolt 4 and USB4 – and up to 120Gb/s for higher display bandwidth needs, you will redefine your productivity.

Easy Port Expansion

Adds more universally compatible Thunderbolt 5 (USB-C) ports to a Mac, PC, or iPad Pro to greatly expand device connectivity possibilities and productivity

Powerful

Safely delivers up to 140 watts to charge the most power-hungry notebook computer

Incomparable Speed

Work and play faster with up to 80Gb/s of bi-directional data speed and up to 120Gb/s for higher display bandwidth needs

Stunning Visuals

Connect to the latest and future Thunderbolt, USB-C, and DisplayPort displays for incredible 4K, 5K, 6K, and up to three 8K displays²

Works with Millions

No worries or confusion…connect to Thunderbolt 5, Thunderbolt 4, Thunderbolt 3, USB4, or USB-C machine or device with 100% compatibility¹

Thunderbolt Certified

Built-in OWC reliability and dependability for Mac and Windows

Best Today, Best Tomorrow

Delivers the best performance of devices with today's computers and best speed possible in the future with a Thunderbolt 5 Mac or PC

Silently Cool

Fanless aluminum enclosure for quiet and cool operation

Multiple Daisy Chains

Create three separate daisy chains of devices – even bus powered – and remove devices from one chain without affecting the other chains

Guaranteed Quality

2 Year OWC Limited Warranty

Bi-Directional Bandwidth Bliss

Give yourself the precious gift of more free time with the OWC Thunderbolt 5 Hub. Its bi-directional design means you can send AND receive data simultaneously at maximum speeds. Connect two OWC Atlas USB4 CFexpress 4.0 Type B Memory Card Readers providing 3300MB/s ingest each while backing up the cards to two high-speed SSDs like the OWC ThunderBlade or OWC Envoy Ultra while exceeding 6000MB/s. With that blissful real-world bit bandwidth, you’ll finish projects faster!

More Pixels and Power Than Ever Before

The OWC Thunderbolt 5 Hub offers more than the fastest bandwidth available to transfer your data and video files. Drive up to three 8K displays² with the OWC Thunderbolt 5 Hub’s Bandwidth Boost technology for up to 120Gb/s – up to 3x faster than Thunderbolt 4 – of intelligent bandwidth allocation for video intensive usage. Send 140W of power delivery to a demanding notebook to keep it powered and ready for mobile use. Quite simply, the OWC Thunderbolt 5 Hub gives you more to do more than ever before.

Create A Tablet ProStation

While iPad Pros and other tablet computers offer awesome content creation potential, they’re handcuffed by limited internal storage, display size, and often a single Thunderbolt (USB-C) port. Instead of lugging around a bulky notebook or worse, being chained to a non-portable desktop workstation, capture what you need on the fly with a tablet. Back at a desk, transform that tablet into a “prostation” with an external display, keyboard, mouse, and external drive all connected to the OWC Thunderbolt 5 Hub.

Thunderbolt 5 is REAL

Intel’s Next-Gen Thunderbolt Technology

With 2x the total bandwidth of previous generations, Thunderbolt 5 unlocks the full potential of Apple’s latest M4 Pro and M4 Max chips. Thunderbolt 5 enables drives and hubs that don’t just move data faster, they move more data faster, sending your workflow into a bottleneck-free bliss.

Certified Satisfaction

All our Thunderbolt connectivity solutions undergo rigorous development testing processes, including intensive mandatory Thunderbolt™ certification. This hyper-focused attention to detail ensures the OWC Thunderbolt 5 Hub will reliably deliver the functionality you expect from your Thunderbolt and USB-C devices.

Technical Specifications:

Device Ports
Host Port
(1) Thunderbolt 5 (USB-C) – up to 80 Gb/s bi-directional data speed and up to 120 Gb/s display bandwidth

Thunderbolt 5 Ports
(3) Thunderbolt 5 (USB-C)

USB Port
(1) USB 3.2 Gen 2 Type-A – up to 10 Gb/s (1250 MB/s), USB 2.0/3.0 backwards compatible

Power Delivery
Host Power Delivery
Up to 140 W (may vary between 100 W and 140 W depending on downstream device usage and host negotiation; some host systems may limit to 100 W maximum)

Thunderbolt 5 Downstream Ports
Up to 15 W per port

USB-A Port
Up to 1.5 A for bus-powered drives and device charging

UASP Support
UASP (USB Attached SCSI Protocol) supported

Display Support
Maximum Display Configurations
Up to three 8K displays @ 60 Hz
or two 8K displays @ 120 Hz
or three 4K displays @ 144 Hz

Display Support by Port
Thunderbolt 5 supports up to two 8K @ 120 Hz or three 4K @ 144 Hz via native Thunderbolt 5 displays or USB-C / DisplayPort 2.1 compatible displays

Power
External Power Adapter
Yes

Power Supply
External UL-listed universal auto-switching

AC Input
100–240 V, 50/60 Hz, 2.5 A

DC Output
+21 V, 8.58 A

Wattage
180 W

Power Button
Yes

Security
Security Slot
Yes

Physical Characteristics
Housing Color
Chassis: Space Gray
Covers: Black

Housing Material
Chassis: Aluminum
Covers: Polycarbonate

Dimensions
Height: 2.2 cm (0.9 in)
Length: 7.8 cm (3.1 in)
Width: 17.8 cm (7.0 in)

Weight
382 g (0.84 lbs)

Certifications and Compliance
Certifications
CE, FCC, ICES, RCM, VCCI, UKCA

RoHS Compliant
Yes

REACH Certification
Yes

UPC
810159628211

Environmental
Ambient Temperature
Operating: 0°C to 30°C (32°F to 86°F)
Non-Operating: -20°C to 60°C (-4°F to 140°F)

Altitude
Operating: -304.8 m to 3,048 m (-1,000 ft to 10,000 ft)
Non-Operating: -304.8 m to 12,192 m (-1,000 ft to 40,000 ft)

Humidity
Operating: 8% to 90% non-condensing
Non-Operating: 5% to 95% non-condensing
