Shuttle BPCAL02 Intel Core i5-1235U Fanless Barebone Box-PC
Key Features
- Dual 2.5 Gigabit Ethernet
- Mounting Options: VESA, Ear mount and DIN rail
- Fanless cooling system
- 24/7 Operation
- Robust aluminium/steel chassis
- Up to 64GB RAM
Shuttle's BPCAL02 fanless Box-PC Series is fuelled by Intel’s 12th Generation (Alder Lake) Core processors in a ruggedised box designed for high durability. It comes with modular I/O expansion capabilities and various mounting options. With advanced technology and highly flexible design, this industrial PC offers a reliable solution for a wide range of customised requirements in industrial environments.
Technical Specification
Product: Shuttle BPCAL02-i5 Fanless Barebone PC
Product type: Barebone Box-PC
Processor family: 12th Generation Intel Core i5
Processor model: i5-1235U
Processor frequency: 3.30 / 4.40 GHz (12MB Cache, 10 Cores)
NPU: Not Supported
Internal memory: Optional, Not Included
Internal memory type supported: Up to 2× DDR5 SO-DIMM Max. 64GB
Total storage capacity: Optional, Not Included
Storage media supported
- The M.2 2280 M slot provides the following interfaces:
- PCI-Express Gen. 4.0 X4
- SATA v3.0 (max. 6 Gbps) - It supports M.2 cards with a width of 22 mm and a length of 42 or 80 mm (type 2242, 2280).
- Supports M.2 SATA SSDs (with B+M key) and M.2 PCIe NVMe SSDs (with M key) with auto detect
On-board graphics card model: Intel UHD Graphics
Connectivity: Optional, Not Included
Connectivity supported: M.2-2230 slot supports WLAN expansion cards
Power: 19V 4.74A 90W External Adapter
Cooling System: Smart Fan
OS Support: Optional, Not Included
- Windows 10 / 11 IoT 64bit
- Linux 64bit
VESA Mount: 75 × 75mm
Ear Mount: 256 × 100mm
Din Rail Mount: 35mm
Dimension (W × H × D): 245 × 57 × 169mm
Weight: 2.85 kg
Warranty: 1-year Carry-in
Ports and Slots
- 2x HDMI 2.0b
- 2x RJ45 (10/100/1000Mbps / 2.5GB)
- 1x RS232 (DB9)
- 2x RS232 / 422 / 485 (DB9)
- 4x USB3.2 Gen 2 (Type-A)4× USB2.0 (Type-A)
- 1x Line-Out
- 1x Mic-In
- 2x External Antenna (Dipole) (Optional, not included)
