The Story
Solarix Solar Charge Controller MPPT 12V 24V 30A SOLMPPT122430
This Solarix Solar Charge Controller archives Maximum power of the solar panel: 30A (Automatically switches between 12V and 24V) this controller-regulator is designed for charging batteries through a solar panel. When the battery voltage is not sufficient, the controller plays a protective role, preventing the voltage from falling below that required to charge the battery.
Product Features
- Humanization LCD Display
- MPPT 4 Stage charging
- Load working mode optional
- Light sensor and timer programmable
- Battery type flood, lead-acid, GEL, Lithium optional
- Charge and discharge current display
- Overall Effective protection
Specifications
- Type: MPPT
- System Voltage: 12V/24Auto
- Solar Panel Maximum Voltage Voc: 100V
- Maximum Open Voltage: 55V – 100V
- Maximum Output Current: 30A
- Solar Panel Power: 390W (12V), 780W (24V)
- Battery voltage: 12V-24V
- Battery Voltage Range: 8-32V
- Battery type: lead acid (sealed, gel) and lithium (also can be customized for different types of batteries)
- Waterproof level: IP30
- Standby power consumption: 8mA (12V), 12mA (24V)
- Overload protection: <10S
Description
Solarix Solar Charge Controller MPPT 12V 24V 30A SOLMPPT122430
This Solarix Solar Charge Controller archives Maximum power of the solar panel: 30A (Automatically switches between 12V and 24V) this controller-regulator is designed for charging batteries through a solar panel. When the battery voltage is not sufficient, the controller plays a protective role, preventing the voltage from falling below that required to charge the battery.
Product Features
- Humanization LCD Display
- MPPT 4 Stage charging
- Load working mode optional
- Light sensor and timer programmable
- Battery type flood, lead-acid, GEL, Lithium optional
- Charge and discharge current display
- Overall Effective protection
Specifications
- Type: MPPT
- System Voltage: 12V/24Auto
- Solar Panel Maximum Voltage Voc: 100V
- Maximum Open Voltage: 55V – 100V
- Maximum Output Current: 30A
- Solar Panel Power: 390W (12V), 780W (24V)
- Battery voltage: 12V-24V
- Battery Voltage Range: 8-32V
- Battery type: lead acid (sealed, gel) and lithium (also can be customized for different types of batteries)
- Waterproof level: IP30
- Standby power consumption: 8mA (12V), 12mA (24V)
- Overload protection: <10S
