Ubiquiti E7 Audience 11500 Mbit/s PoE Wireless Access Point

Ubiquiti E7 Audience 11500 Mbit/s PoE Wireless Access Point

Enterprise-grade indoor access point designed for high-density environments with 12-stream 5 GHz and 6 GHz WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability.

Technical Specifications:

Dimensions
Device: 474.1 × 265.5 × 42.2 mm (18.7 × 10.5 × 1.7")
Bracket: 150.4 × 113.6 × 125 mm (5.9 × 4.5 × 4.9")

WiFi Standard
WiFi 7

Spatial Streams
12

Coverage Area
465 m² (5,000 ft²)

Max. Client Count
1500+

Uplink
10 GbE
1 GbE

Mounting
Wall, Pole (Mounts Included)
VESA (Optional)

Weatherproofing
IP68

Power Method
PoE++

Performance

MIMO

6 GHz
Low Band: 4 × 4 (DL/UL MU-MIMO)
High Band: 4 × 4 (DL/UL MU-MIMO)

5 GHz
4 × 4 (DL/UL MU-MIMO)

Max. Data Rate

6 GHz
Low Band: 11.5 Gbps (BW320)
High Band: 11.5 Gbps (BW320)

5 GHz
8.6 Gbps (BW240)

Antenna Gain

6 GHz
Directional internal: 15 dBi, 50° × 50°
Directional internal: 11 dBi, 90° × 90°

5 GHz
Directional internal: 15 dBi, 50° × 50°
Directional internal: 11 dBi, 90° × 90°

Max. TX Power

6 GHz
Low Band: 30 dBm (36 dBm EIRP)
High Band: 30 dBm (36 dBm EIRP)

5 GHz
30 dBm

Max. BSSIDs
8 per Radio

Supported Data Rates

802.11be (WiFi 7)
7.3 Mbps – 11.5 Gbps (MCS0–MCS13, NSS1/2/3/4, EHT 20/40/80/160/240/320)

802.11ax (WiFi 6)
7.3 Mbps – 4.8 Gbps (MCS0–MCS11, NSS1/2/3/4, HE 20/40/80/160)

802.11ac (WiFi 5)
6.5 Mbps – 3.4 Gbps (MCS0–MCS9, NSS1/2/3/4, VHT 20/40/80/160)

802.11n
6.5 Mbps – 600 Mbps (MCS0–MCS31, HT 20/40)

Features

Wireless Meshing: Yes
Band Steering: Yes
802.11v BSS Transition Management: Yes
802.11r Fast Roaming: Yes
802.11k Radio Resource Management (RRM): Yes
Zero-Wait DFS: Yes
Advanced Radio Management: Yes
Real-Time Spectral Analysis: Yes
Passpoint (Hotspot 2.0): Yes

Captive Hotspot Portal
Custom Branding Landing Page: Yes
Voucher Authentication: Yes
Payment-Based Authentication: Yes
External Portal Server Support: Yes
Password Authentication: Yes

Guest Network Isolation: Yes
Private Pre-Shared Key (PPSK): Yes
WiFi Speed Limiting: Yes
Client Device Isolation: Yes
WiFi Schedules: Yes
RADIUS over TLS (RadSec): Yes
Dynamic RADIUS-assigned VLAN: Yes

Hardware

Max. Power Consumption
51W

Supported Voltage Range
42.5–57V DC

Networking Interface
(1) 10 GbE RJ45 port
(1) GbE RJ45 port

PRISM™ RF Filtering
Yes

Weight
Device: 3.3 kg (7.3 lb)
With mount: 4.3 kg (9.5 lb)

Wind Loading
164.75 N at 200 km/h (37 lbf at 125 mph)

Pole Mount Diameter
1–3" (25–76 mm)

Antennas
Internal directional antennas

Management
Ethernet

Enclosure Material
UV-stabilized polycarbonate, aluminum alloy

Mount Material
Aluminum alloy

LEDs
System: R/G/B

Channel Bandwidth
VHT 20/40/80/160
HE 20/40/80/160
EHT 20/40/80/160/240/320 (MHz)

NDAA Compliant
Yes

Certifications
FCC, IC

Operating Frequency

US/CA
U-NII-1: 5150–5250 MHz
U-NII-2A: 5250–5350 MHz
U-NII-2C: 5470–5725 MHz
U-NII-3: 5725–5850 MHz
U-NII-5 & U-NII-7: 5925–6425 MHz, 6525–6875 MHz

Worldwide
5150–5725 MHz
5925–7125 MHz

Environment

Ambient Operating Temperature
-40 to 60°C (-40 to 140°F)

Ambient Operating Humidity
5%–95% noncondensing
